Atlantic alfea extensa duo+ - Product Description; Package Contents; Technical Definitions

1 Description of the unit
1.1 Package
• 1 package: Outdoor unit.
• 1 package: Hydraulic unit and outdoor sensor.
1.2 Denitions
- Split: The heat pump consists of two elements
(an outdoor unit for outdoor and a hydraulic unit for
inside the dwelling).
- Air/water: The surrounding air is the energy source.
This energy is transmitted to the water in the heating
circuit by the heat pump.
- Inverter: the fan and compressor speeds are modulated
according to the heating requirements. This technology
enables you to save on energy and operate on a single-
phase power supply, whatever the heat pump's output,
by avoiding heavy intensities on start-up.
- COP (coefcient of performance): this is the relationship
between the energy transmitted to the heating circuit
and electrical energy consumed.
Installation and operating manual "1578 - EN"
Heat Pump alféa extensa duo +
- 4 -
Packing list
Heat pump (HP) Outdoor unit Hydraulic unit
Model Code Model Code Model Code
alféa extensa duo + 5 522929
WOYA060LDC 700164
MH extensa duo + 5 023208
alféa extensa duo + 6 522930
MH extensa duo + 6-10 023209alféa extensa duo + 8 522931 WOYA080LDC 700165
alféa extensa duo + 10 522932 WOYA100LDT 700166
Scope of application
This heat pump provides:
- Heating in winter,
- Control of two heating circuits*,
- Production of domestic hot water.
- Installation with boiler connection* as a
supplementary heating for the coldest days.
or
- the addition of electrical back-ups*, for extra heating
on the coldest days.
- Cooling in summer* (for oor heating-cooling system
or fan-convectors).
- Heating the swimming pool*.
* : These options require the use of additional kits
(see para "Optional equipment").
Optional equipment
• 2nd circuit kit (code 074011)
for connecting 2 heating circuits.
• Regulation extension kit (code 075311)
to manage a 2nd heating circuit, swimming pool etc...
• Boiler connection kit (code 073990)
for connecting a boiler to the heat pump.
• Electrical back-ups kit (code 073985).
• Room thermostat T37 (code 075308),
Room thermostat T55 (code 073951),
Room thermostat radio T58 (code 075313)
- for correcting the ambient temperature.
• Room control unit T75 (code 073954),
Room control unit radio T78 (code 074061)
for correcting the ambient temperature and
programming the heat pump.
• Anti-vibration blocks (code 523574).
• White PVC oor support (code 809532) or
Black rubber oor support (code 809536).
• Swimming pool kit (code 074726).
• Cooling kit (code 075312).
• High ow rate circulating pump kit (code 074077)
for the installation of 1 circuit oor heating
(with model > 13 kW).
