7 Maintenance
7.1 Maintenance
General recommendations and precautions
The dryer does not need any specific maintenance. Nevertheless, before carrying out any maintenance or
corrective activity, read the following recommendations and safety precautions and act accordingly:
• Pull out the power cord or put the on/off switch S1 in the OFF position (whichever is applicable).
• Disconnect all pressure sources and vent the internal pressure of the system before dismantling any
pressurized component.
• Use genuine Atlas Copco spare parts only. Consult the Spare Parts List for part numbers. For
preventive maintenance, dedicated Service kits are available.
• Check for correct operation after maintenance.
Filters and valves installed between the compressor, the dryer and the air consumer
may need other maintenance activities than those mentioned below (e.g. draining the
filters and replacing the filter elements). Refer to the appropriate manual for more
information.
Preventive maintenance schedule
Frequency Service Plan Activity
Daily Check the display panel. Service information
can be found here.
Every 6 months • Check for damaged wiring or loose
connections.
• Check for air leaks.
Every year or every 6000 hours of operation
(1)
A • Replace the inlet filter cartridge.
• Replace the silencers.
Every 2 years or every 12000 hours of
operation (1)
B • Service plan A.
• Replace desiccant cartridges.
Every 4 years or every 24000 hours of
operation (1)
C • Service plan B.
• Replace exhaust valve diaphragm and
solenoid valves.
• Replace shuttle valve and o-rings.
(1) whichever comes first
It is recommended to have the desiccant replaced by a qualified Atlas Copco service technician.
At each 12000 hours service interval, the timer card needs to be reset with a magnetic key, see section
Resetting the service counter or the instruction, delivered with the service kits.
All spare parts required for scheduled maintenance are included in specific service kits. Consult the spare
parts list for part number information.
