Step Description Figure
8 Put the top plate back on, making sure the O-
ring is in place.
9 Finally tighten the M10 bolts making sure there
are no leaks.
10 Repeat steps 2 to 9 for the other tower of the
dryer.
11 Follow the start-up procedure described in
section Operating instructions.
