Atlas Copco CD 1+ - Page 57

Specification Unit
CD 1
+
CD 1.5
+
CD 2
+
CD 2.5
+
CD 3
+
Mass kg 7 8 9 10 11
lb 15.5 17.6 19.8 22 24.2
Installed power (max) VA 8 8 8 8 8
Time of half a cycle s 170 170 170 170 170
Regeneration time s 120 120 120 120 120
Specification Unit
CD 5
+
CD 7
+
CD 10
+
CD 12
+
CD 17
+
CD 22
+
Max. volume flow at
dryer inlet
l/s 5 7 10 12 17 22
cfm 10.6 14.8 21.2 25.4 36 46.6
Regeneration air
consumption average
at max. flow
% 18 18 18 18 18 18
Filter size PD 9 9 9 17 17 17
Mass kg 19 22 25 29 35 44
lb 41.9 48.5 55.1 63.9 77.1 97
Installed power (max) VA 8 8 8 8 8 8
Time of half a cycle s 170 170 170 170 170 170
Regeneration time s 120 120 120 120 120 120
Specific data for CD 1
+
up to CD 22
+
(special version, PDP -70 °C)
Desiccant type: molecular sieves
Specification Unit
CD 1
+
CD 1.5
+
CD 2
+
CD 2.5
+
CD 3
+
Max. volume flow at dryer
inlet
l/s 0.7 1.05 1.4 1.75 2.1
cfm 1.5 2.2 3 3.7 4.4
Regeneration air
consumption average at
max. flow
% 25 25 25 25 25
Filter size PD 3 3 3 3 3
Mass kg 7 8 9 10 11
lb 15.5 17.6 19.8 22 24.2
Installed power (max) VA 8 8 8 8 8
Time of half a cycle s 170 170 170 170 170
Regeneration time s 120 120 120 120 120
Specification Unit
CD 5
+
CD 7
+
CD 10
+
CD 12
+
CD 17
+
CD 22
+
Max. volume flow
at dryer inlet
l/s 3.5 4.9 7 8.4 11.9 15.4
cfm 7.4 10.3 14.8 17.8 25.1 32.6
Regeneration air
consumption
average at max.
flow
% 25 25 25 25 25 25
Instruction book
2920 7083 21 55
