Step Action
1 Stop the compressor, close the air outlet valve and switch off the voltage. Wait a few
minutes and depressurize the air receiver by unscrewing the oil filler plug (of the air
receiver) only one turn to permit any pressure in the system to escape.
2 Use an oil pan to avoid possible oil spillage. Unscrew the oil filters only one turn and
wait a few minutes to let the oil of the filter flow back into the oil separator. Remove the
oil filters.
3 Clean the filter seats on the manifold. Oil the gaskets of the new filters and screw the
filters into place until the gaskets contact their seats. Then tighten with a maximum
torque of 10 Nm.
4 Tighten the oil filler plug (of the air receiver).
5 Reset the service warning after carrying out all service actions in the relevant Service
Plan. Refer to the Service menu section.
6.6 Storage after installation
Procedure
Run the compressor, e.g. twice a week, until warm.
If the compressor is going to be stored without running from time to time, protective
measures must be taken. Consult the Atlas Copco Customer Centre.
6.7 Service kits
General
Service kits comprise all parts needed for servicing components and offer the benefits of genuine
Atlas Copco parts while keeping the maintenance budget low. All service kits are indicated in the
relevant Parts Lists.
Atlas Copco Roto-Xtend Duty Fluid
Roto-Xtend Duty Fluid can be ordered in the following quantities:
• 5-litre can: 2901 1700 00
• 20-litre can: 2901 1701 00
• 209-litre drum: 2901 1702 00
See Oil specifications.
Instruction book
APF221384 69
