Rear view, GA 75 VSD and GA 90 VSD Workplace
Reference Name
AR Air receiver
AV Air outlet valve
Ca Air cooler
Co Oil cooler
CV/Vs Check valve/oil stop valve
Da Automatic condensate outlet
E Compressor element
ER Elektronikon II regulator
FN Cooling fan
MT Condensate trap
M1 Drive motor
OF Oil filter
S3 Emergency stop button
VP Vent plug
1 Electric cabinet
GA Workplace Full-Feature
GA Workplace Full-Feature (FF) are enclosed in a sound-insulated bodywork. The compressors are controlled
by the Atlas Copco Elektronikon® II regulator. The electronic control module is fitted to the door at the right
Instruction book
12 2920 1634 04
