Instruction book
7.4.4 Fan motor circuit breakers
Fan type Frequency Supply Circuit Max. setting of
voltage breaker circuit breaker
(Hz) (V) (A)
Cooling fan for air- and oil coolers (GR110/160) 50 230 Q25/26 12.4
Cooling fan for air- and oil coolers (GR110/160) 50 400 Q25/26 7.2
Cooling fan for air- and oil coolers (GR110/160) 50 500 Q25/26 5.7
Cooling fan for air- and oil coolers (GR200) 50 230 Q25/26 17.1
Cooling fan for air- and oil coolers (GR200) 50 400 Q25/26 9.9
Cooling fan for air- and oil coolers (GR200) 50 500 Q25/26 7.7
Cooling fan for air- and oil coolers (GR110/160) 60 220-230 Q25/26 14.3
Cooling fan for air- and oil coolers (GR110/160) 60 380 Q25/26 8.6
Cooling fan for air- and oil coolers (GR110/160) 60 440-460 Q25/26 7.2
Cooling fan for air- and oil coolers (GR110/160) 60 575 Q25/26 5.7
Cooling fan for air- and oil coolers (GR200) 60 220-230 Q25/26 20.2
Cooling fan for air- and oil coolers (GR200) 60 380 Q25/26 11.7
Cooling fan for air- and oil coolers (GR200) 60 440-460 Q25/26 9.9
Cooling fan for air- and oil coolers (GR200) 60 575 Q25/26 7.7
Bodywork ventilation fan (GR110/200 W) 50 230 Q25 2.5
Bodywork ventilation fan (GR110/200 W) 50 400 Q25 1.4
Bodywork ventilation fan (GR110/200 W) 50 500 Q25 1.1
Bodywork ventilation fan (GR110/200 W) 60 220-230 Q25 2.1
Bodywork ventilation fan (GR110/200 W) 60 380 Q25 1.4
Bodywork ventilation fan (GR110/200 W) 60 440-460 Q25 1.1
Bodywork ventilation fan (GR110/200 W) 60 575 Q25 1.1
7.4.5 Circuit breakers for dryer motor (GR Full-feature)
Type Frequency Supply voltage Max. setting of circuit breaker Q40
(Hz) (V) (A)
GR110/160 dryer motor 50 230 28
GR110/160 dryer motor 50 400 16
GR110/160 dryer motor 50 500 13
GR200 dryer motor 50 400 27
GR200 dryer motor 50 500 22
GR110 dryer motor 60 220-230 25
GR110 dryer motor 60 380 15
GR110 dryer motor 60 440-460 13
GR110 dryer motor 60 575 10
GR160 dryer motor 60 380 22
GR160 dryer motor 60 440-460 19
GR160 dryer motor 60 575 15
GR200 dryer motor 60 380 38
GR200 dryer motor 60 440-460 33
GR200 dryer motor 60 575 25
