2920 1449 00
37
Instruction book
7.4.6 Circuit breakers for dryer cooling fan motor (GR Full-feature)
Type Frequency Supply voltage Max. setting of circuit breaker Q41
(Hz) (V) (A)
GR110/160 dryer cooling fan motor 50 230 2.5
GR110/160 dryer cooling fan motor 50 400 1.4
GR110/160 dryer cooling fan motor 50 500 1.1
GR200 dryer cooling fan motor 50 400 6.2
GR200 dryer cooling fan motor 50 500 5.1
GR110/160 dryer cooling fan motor 60 220-230 3.6
GR110/160 dryer cooling fan motor 60 380 2.2
GR110/160 dryer cooling fan motor 60 440-460 1.9
GR110/160 dryer cooling fan motor 60 575 1.4
GR200 dryer cooling fan motor 60 380 8.8
GR200 dryer cooling fan motor 60 440-460 7.7
GR200 dryer cooling fan motor 60 575 5.9
7.4.7 Circuit breaker for control circuit (Q1)
Type Frequency Supply Transfo Transfo Transfo Transfo
voltage T1 250 VA T1 400 VA T1 630 VA T1 800 VA
(Hz) (V) (A) (A) (A) (A)
GR110/160 50 230 1.5 2.4 3.6 4.5
GR110/160 50 400 0.9 1.4 2.2 2.8
GR110/160 50 500 0.7 1.1 1.8 2.2
GR200 50 400 0.9 1.4 2.2 2.8
GR200 50 500 0.7 1.1 1.8 2.2
GR110/160 60 220-230 1.6 2.4 3.7 4.7
GR110/160 60 380 0.9 1.4 2.2 2.8
GR110/160 60 440-460 0.8 1.2 1.9 2.4
GR110/160 60 575 0.6 0.92 1.4 1.8
GR200 60 380 0.9 1.4 2.2 2.8
GR200 60 440-460 0.8 1.2 1.9 2.4
GR200 60 575 0.6 0.92 1.4 1.8
