Instruction book
1 By-pass valve
2 By-pass valve
3 By-pass valve
4 Oil coolers
5 Vent plug
6 Air cooler
7 Cooling fan
8 Minimum pressure
valve
9 Oil drain plug, air
receiver
10 Air receiver
11 Oil filters
12 Condensate trap
13 Air dryer
14 Condensate outlets
15 Compressed air outlet
16 Air filter
M25 Fan motor
Fig. 1.2 Rear view GR200 FF
1 Pipe, air receiver to air cooler
2 Safety valve
3 Air cooler
4 Bolts
5 Oil coolers
6 Filler plug (only to be used at initial
start-up)
7 Unloader
8 Air inlet hose
9 Compressor element, low pressure
10 Check valve
11 Compressor element, high pressure
12 Oil drain plug, air receiver
13 Air receiver
14 Oil filters
15 Oil separator element
16 Receiver cover
17 Bolt
18 Minimum pressure valve
19 Arrow, rotation direction fan motor
20 Cooling fan
M25/M26 Fan motor
Y1 Loading solenoid valve
Fig. 1.3 Side view GR200 FF
M25
1
2
3
4
5
67
8
9
1011
1213
14
15
16
51437F
1 M25
23
4
5
6
7
M26
Y1
8
9
10
11
12
13
14
15
16
17
18
19
51438F
20
19
