Atlas Copco Tensor STB User Manual

Parameters, relays and events
24 (36) 9836 3043 01
Event
code
Event name
Description
Procedure
Acknowledge
PF ready
Tool not ready
E555
Condition change not
reflected in tool,
wireless tool
inaccessible
A condition change in the controller
(Pset selection, Job selection, Job
aborted etc.) could not be reflected in
the tool. The tool was currently
inaccessible.
Re-establish connection.
The condition change is now
automatically transferred to the
tool.
E556
Tool battery low
Tool battery voltage is low.
Complete work and replace
battery.
E557
Tool battery empty
Tool battery voltage is empty. Tool
locked
Replace the battery.
The tool is unlocked
automatically.
E558
Tool software
version mismatch
The implemented protocol version in
Power Focus for connected tool differs
from the protocol version in tool.
Additional parameter information:
First parameter is Power Focus protocol
version second parameter is Tool
protocol version.
Upgrade the software in tool or
Power Focus.
E559
IRC pairing
completed
An IRC paring sequence has been
successfully completed.
For information only.
E561
Tool locked, do
Store standalone
Tool locked since no Pset has been
actively stored in the tool.
Do Store Standalone or deselect
Standalone, parameter T470
Use Standalone.
E562
Condition change not
reflected in tool,
wireless tool
standalone
A condition change in the controller
(Pset selection, Job selection, Job
aborted …) could not be reflected in the
tool. The tool was currently standalone
Make changes in the standalone
interface instead if the change
is meant to apply.
E563
IRC configuration
mismatch
Not possible to establish radio
connection with wireless tool.
Check if tool is in correct
operation mode (Ad-hoc and
not Infrastructure mode) and
the PF IRC settings.
x
E564
Reboot of wireless
tool needed for
changes to take
effect
Reboot of wireless tool needed for
changes to take effect.
Acknowledge the event on the
PF and power cycle the
wireless tool
x
E565
Locked while
updating Pset/Job in
tool
The controller has locked the tool while
updating the Pset/Job in the tool.
For information only. The tool
trigger was pressed before the
tightening programme was
fully read by the tool.
x
E601
System voltage low
DC voltage too low. Tool locked.
Acknowledge the event.
Check the battery. If occurring
frequently, check Pset settings.
Lastly, service tool.
x
x
x
E602
Dcbus HI during
rundown
DC voltage too high
x
x
x
E620
Tool stall
Tool motor stall.
Check that the tool cable and
connectors are undamaged and
correctly connected.
If possible use a shorter tool
cable.
For STB, see E601 System
voltage low.
E621
Current
measurement error
Current cannot be measured correctly.
Contact the Atlas Copco
service representative if it
occurs frequently.
x
