Appendix
34 (36) 9836 3043 01
2. In ToolsTalk, open Option > Settings > Power Focus List and check that the Power Focus is present
in the Power Focus list.
3. Connect the Power Focus.
Troubleshooting the connection
If no connection is established, do the following to check that the network configuration is correct.
1. In the PC, open up the start menu, and click Run.
2. Type cmd and then click OK. The command prompt window opens.
3. Type ipconfig in that window, and then press the enter key. The IP configuration of this PC is
displayed. Verify that it matches the settings of the Power Focus, except for the last digit group of
the IP address that must be different. In this example it is 1 for the controller and 128 for the PC.
4. Type ping followed by the IP address of the Power Focus. In the example, type ping 192.168.1.1.
5. Press the Enter key. A reply message from the Power Focus should now be displayed.
