- 45 -
Press the load button, the display will show
When the load button is pressed and the measured
vessel pressure is lower then 4.5 bar, the controller
will run a specific program to reach the requested
4.5 bar, in order to be able to load the machine.
The engine will now run at maximum rpm, the display
will show
The loading valve will be energized and pressure
starts building up.
During loading the following display is shown
(default display)
The controller controls the speed of the engine in
order to meet the requested working pressure, at the
most economical fuel usage.
Active Buttons
Active Buttons
MAIN VIEW
BUILDING UP VESSEL PRESSURE
3.9
1200RPM 3.9bar41% 1286h
Active Buttons
VUE PRINCIPALE
CHARGE EN PRÉPARATION
1,2
1650
RÉGIME
1286h
40%
430 L/s
MAIN VIEW
LOADED
7.2
1424RPM 7.2bar1286h
40%
