Atlas Copco U190 PACE KD WUX

- 81 -
PERFORMANCE DATA
1)
Designation Unit U190 PACE
Engine shaft speed, normal and maximum
- At pressure setting 5 (bar(g)) r/min 3000
- At pressure setting 7 (bar(g)) r/min 3000
- At pressure setting 10.5 (bar(g)) r/min 2200
Engine shaft speed, compressor unloaded r/min 1600
Free air delivery
2) 6)
- At pressure setting 5 (bar(g)) l/s 90
cfm 190
- At pressure setting 7 (bar(g)) l/s 90
cfm 190
- At pressure setting 10.5 (bar(g)) l/s 42
cfm 90
Fuel consumption
- at 100% FAD kg/h 8.52
lb/h 18.78
- at 75% FAD kg/h 7
lb/h 15.43
- at 50% FAD kg/h 5.27
lb/h 11.61
- at 25% FAD kg/h 3.59
lb/h 7.91
- at unload kg/h 2.69
lb/h 5.93
