Atlas Copco XAS 185 KD7 T4 User Manual

- 45 -
Performance data
1)
Design Data
COMPRESSOR
ENGINE
UNIT
Designation XAS 185 KD7
Engine shaft speed, normal and maximum rpm 2700
Engine shaft speed, compressor unloaded rpm 1600
Free air delivery
2)
l/s 83.53
cfm 177
Fuel consumption -at full load gal/hr 2.33
-at unload gal/hr 0.94
Specific fuel consumption gal/ft
3
0.00022
Typical oil content of compressed air mg/m
3
<5
oz/1000 cu.ft < 0.005
Engine oil consumption (maximum) g/hr NA
oz/h NA
Compressed air temperature at outlet valves °C 93.3
°F 200
Noise level
6)
dB(A) <76
Designation All units
Number of compression stages 1
Designation XAS 185 KD7
Make Kubota
Type V2403
Coolant
Ethylene glycol mix w/SCA
package
Number of cylinders 4
Bore
in 3.43
mm 87.12
Stroke
in 4.03
mm 102.36
Swept volume
cu.in 148.53
l2.43
Output at normal shaft speed
5)
hp 49
kW 36.53
- Load factor % 80
Capacity of oil sump
qts 10
gal 2.5
-Refill (max.)
4)
qts 11
gal 2.75
Capacity of cooling system
qts 10
gal 2.5
Designation All units
Capacity of compressor oil system
qts 12.2
gal 3.05
Net capacity of air receiver
US gal 4.5
l 17.03
Capacity of fuel tanks
US gal 20.1
l 76.08
Air volume at inlet grating (approx.)
3)
cfm 6340
m
3
/s 2.99
Designation XAS 185 KD7
