Machine Composition 10
Atlas Cyclops
3.2 Managing PC
Software is installed on managing PC (personal computer), positioned inside
cabin. EPIA managing PC M830 features:
• Processor VIA Nano 1.3GHz.
• RAM 1 Gb;
• Smart card reader
• 6 USB; 1 LAN Ethernet 10/100Mb;
• Windows 7 operating system, English version
• 1366x768 Pixels HD Ready video output
• Hard Disk ≥ 160 Gb
3.3 3D cameras
The Cyclops 3D cameras do not need any cable or cord connection for angle
measurement or data transmission. Detecting units consist of 2 megapixel
cameras for each 3D camera. Each camera features a set of high effi ciency
infrared LED’s, used to light the 3D targets fi tted on the wheels of the vehicle.
Data is transmitted directly VIA RADIO through
modules located inside
the 3D cameras and cabin.
Characteristic angles of both axles of the vehicle are controlled and compensated
by 4 CCD sensors and 2 electronic inclinometers located inside the two 3D
cameras. Data transmission among infrared 3D cameras is effective also under
critical lighting conditions.
Power is supplied by rechargeable 12V long-lasting batteries. Batteries are
recharged when they are inserted into the recharge supports located on the
cabin (see part 3.1).
WARNI NG: always swit ch 3D cam eras off upon rem oving and/ or insert ing t he
bat t eries; m anual swit ch- off is carried out by pressing sim ultaneously t he m ost
external red and green but t ons (see part 3.3.1) .
For 3D cameras with rechargeable batteries, power supply and consumption
data are the following:
Power supply
NiMH battery (NICKEL-METAL HYDRIDE)
12V- 4Ah
Average operation with fully
effective and charged battery
Approx. 8 hours
Average recharge time Approx. 12 hours
