Atlas Cyclops User Manual

System Features 16
Atlas Cyclops
Syst em Feat ures
4.1 Safety Devices
The Cyclops features a master switch positioned on the rear of the machine. The
master switch cuts off machine power when set to “0”.
4.2 Measurement Range and Accuracy
Ax le Mea sure m ent Accuracy
Mea sure m ent
Range
Mea sure m ent
Total Range
Front
Toe ± 2’ ± 2° ± 20° x 2
Partial toe ± 1’ ± 1° ± 20°
Set-back ± 2 ± 2° ± 5°
Camber ± 2’ ± 3° ± 10°
Caster ± 5’ ± 10° ± 18°
Kingpin ± 5’ ± 10° ± 18°
Rea r
Toe ± 2’ ± 2° ± 20° x 2
Partial toe ± 1’ ± 1° ± 20°
Set-back ± 2’ ± 2° ± 5°
Camber ± 2’ ± 3° ± 10°
Thrust angle ± 2’ ± 2° ± 5°
