Intended Use 7
Atlas Cyclops
I ntended Use
The Atlas Cyclops system is a machine designed for detection of all vehicle
special angles. Applications: double axle cars and light commercial vehicles with
wheelbases ranging between 5’ 11” (min.) and 15’ 5” (max.).
Infrared measurements of reciprocal angles are detected by two 3D cameras
placed between the front and rear wheels, each fi tted with two megapixel
cameras which detect the spatial position of 4 three-dimension targets on the
wheels (no cable connections). Data is transmitted from 3D cameras to cabin
VIA RADIO through
.
Machine operational temperature range: 32 to 100°F.
