Database Customization 64
Atlas Cyclops
3D Camera Keypad Pc Keyboard Description
Goes back to the
Introduction page.
(see Figure 10)
Moves selection up.
Moves selection down.
As you can see from the zoom on the right side of Figure 54, you will have to
specify if the point datum refers to can be adjusted or not.
The point to which the data
refer can be adjusted. To defi ne
it as not-adjustable, press:
The point to which the data
refer cannot be adjusted. To
defi ne it as adjustable, press:
Once the desired option
has been selected, press:
Once angle “adjustability” has been specifi ed, you can enter the gra phic
anim at ions. Select the correct image or animation with keys
, then
press “Enter” to confi rm
Now you shall enter vehicle standard tolerance values as for:
FRONT AXLE: REAR AXLE:
• To e • To e
• Camber • Camber
• Caster • Thrust angle
• Kingpin
• Included angle
• Max. steering
Select data as described above, and enter values.
