Installation Steps 29

PV-10PX / PV-10HPX

2. Low setting cable connection. For a ceiling height between 4250mm (167

3/8”) and 4350mm (171 1/4”).

Low Setting

Cable 2

Cable 1

Cable 2

Fig. 34
