Atmel AVR AT90S2323 User Manual

62
AT90S/LS2323/2343
1004D–09/01
Packaging Information
8P3
10.16(0.400)
9.017(0.355)
PIN
1
7.11(0.280)
6.10(0.240)
.300 (7.62) REF
5.33(0.210) MAX
254(0.100) BSC
0.381(0.015)MIN
0.559(0.022)
0.356(0.014)
3.81(0.150)
2.92(0.115)
1.78(0.070)
1.14(0.045)
8.26(0.325)
7.62(0.300)
10.90(0.430) MAX
0.356(0.014)
0.203(0.008)
4.95(0.195)
2.92(0.115)
Seating Plane
*Controlling dimension: Inches
8P3, 8-lead, Plastic Dual Inline
Package (PDIP), 0.300" Wide.
Dimensions in Millimeters and (Inches)*
JEDEC STANDARD MS-001 BA
1.524(0.060)
0.000(0.000)
REV. A 04/11/2001
