Atmel AVR ATtiny15L - Page 60

ATtiny15L
60
Figure 39. Analog Comparator Input Leakage Current
Figure 40. Watchdog Oscillator Frequency vs. V
CC
Sink and source capabilities of I/O ports are measured on one pin at a time.
60
50
40
30
20
10
0
-10
0 0.5 1.51 2 2.5 3.53 4 4.5 5 6 6.5 75.5
ANALOG COMPARATOR INPUT LEAKAGE CURRENT
T = 25˚C
A
I (nA)
ACLK
V (V)
IN
V = 6V
CC
0
200
400
600
800
1000
1200
1400
1600
1,5 2 2,5 3 3,5 4 4,5 5 5,5 6
T = 85˚C
A
T = 25˚C
A
WATCHDOG OSCILLATOR FREQUENCY vs. V
cc
V (V)
cc
F (KHz)
RC
