ATtiny15L
67
ATtiny15L Instruction Set Summary (Continued)
Mnemonics Operands Description Operation Flags #Clocks
DATA TRANSFER INSTRUCTIONS
LD Rd, Z Load Register Indirect Rd
← (Z) None 2
ST Z, Rr Store Register Indirect (Z)
← Rr None 2
MOV Rd, Rr Move Between Registers Rd
← Rr None 1
LDI Rd, K Load Immediate Rd
=← KNone1
IN Rd, P In Port Rd
← PNone1
OUT P, Rr Out Port P
← Rr None 1
LPM Load Program Memory R0
←=(Z) None 3
BIT AND BIT-TEST INSTRUCTIONS
SBI P, b Set Bit in I/O Register I/O(P,b)
← 1None2
CBI P, b Clear Bit in I/O Register I/O(P,b)
← 0None2
LSL Rd Logical Shift Left Rd(n+1)
← Rd(n), Rd(0) ← 0 Z,C,N,V 1
LSR Rd Logical Shift Right Rd(n)
← Rd(n+1), Rd(7) ← 0 Z,C,N,V 1
ROL Rd Rotate Left Through Carry Rd(0)
←C,Rd(n+1)← Rd(n),C←Rd(7) Z,C,N,V 1
ROR Rd Rotate Right Through Carry Rd(7)
←C,Rd(n)← Rd(n+1),C←Rd(0) Z,C,N,V 1
ASR Rd Arithmetic Shift Right Rd(n)
← Rd(n+1), n=0..6 Z,C,N,V 1
SWAP Rd Swap Nibbles Rd(3..0)
←Rd(7..4),Rd(7..4)←Rd(3..0) None 1
BSET s Flag Set SREG(s)
← 1 SREG(s) 1
BCLR s Flag Clear SREG(s)
← 0 SREG(s) 1
BST Rr, b Bit Store from Register to T T
← Rr(b) T 1
BLD Rd, b Bit load from T to Register Rd(b)
← TNone1
SEC Set Carry C
← 1C1
CLC Clear Carry C
← 0 C 1
SEN Set Negative Flag N
←=1N1
CLN Clear Negative Flag N
← 0 N 1
SEZ Set Zero Flag Z
← 1Z1
CLZ Clear Zero Flag Z
← 0 Z 1
SEI Global Interrupt Enable I
← 1I1
CLI Global Interrupt Disable I
← 0 I 1
SES Set Signed Test Flag S
← 1S1
CLS Clear Signed Test Flag S
← 0 S 1
SEV Set Twos Complement Overflow V
=← 1V1
CLV Clear Twos Complement Overflow V
← 0 V 1
SET Set T in SREG T
=← 1T1
CLT Clear T in SREG T
←=0 T 1
SEH Set Half-carry Flag in SREG H
← 1H1
CLH Clear Half-carry Flag in SREG H
← 0 H 1
NOP No Operation None 1
SLEEP Sleep (see specific descr. for Sleep function) None 3
WDR Watch Dog Reset (see specific descr. for WDR/timer) None 1
