55
SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
5.1.1 Equipment List
The SAMA5D3 series MB is a full-featured motherboard. It can be used with all available SAMA5D3 series CM boards.
5.1.2 Technical Specifications
Note: Some of the features mentioned in the above feature summary table are optional. Check the article number of
your module and compare it to the option information list on Table 3-1 “Evaluation Kit Features” of this user
guide to determine which options are available with your particular module.
Table 5-1. MB Technical Specifications
Characteristic Specifications
Supported Module All SAMA5D3 series computer modules
Expansion Slots One 200-pin SODIMM socket
Mass Storage Interface Two high-speed memory card hosts
1 x SD card slot (can also read MMC cards)
1 x micro SD card slot
I/O
3 x 20 pin header
1 x 20 + 1 x 15 pin header LCD connector
1 x 10 pin header ISI connector (Image Sensor)
One 1-Wire EEPROM DS28EC20
One power LED
Communication
1 x Gigabit Ethernet
1 x 10/100 MHz Ethernet
2 x USB High-speed 2.0 Host
1 x USB High-speed 2.0 Host/Device
1 x USARTs, 1 x DBGU
2 x CAN connectors
1 x 10-pin header ZigBee connector
1 x Smart DAA (Softmodem interface)
Sound Wolfson's 8904 Mic in, Headphone out signals
Video 1 x HDMI
LCD
LCD TFT Controller with overlay, alpha-blending, rotation, scaling and color
space conversion
ISI ITU-R BT. 601/656 Image Sensor Interface
Debug
1 x On-board SAM-ICE
™
1 x Bridge USB/UART DBGU
CMOS Battery On-board Lithium Battery for CMOS backup
Power
System power: +5V DC +/-5%
Backup: +1.65V to 3.6V DC
RoHS status Compliant
CE and FCC Part 15 status Compliant
Dimensions 165 * 135 * 20 mm
