5.1.3 Devices
List of the MB board peripherals:
 Two EMAC PHY
 One audio CODEC
 Two high-speed MCI card interfaces
 Two CAN transceivers
 One RS232 port with level translator features USART1
 One Smart DAA port
 Two USB host ports
 One USB host/device port
 On-board power regulation
 LCD/ISI extension interface
 HDMI interface
 ZigBee
®
interface
 One-wire device
5.1.4 Board Interface Connection
 Main power supply (J4)
 200 positions socket (as defined in SODIMM 200), 0.6mm pitch (J12)
 USB A Host/Device, support USB host/device using a micro AB connector (J20)
 USB B Host, support USB host using a type A connector (J19, upper)
 USB C Host, support USB host using a type A connector (J19, lower)
 USB-to-serial bridge on DBGU, and JTAG-OB functionality (J14)
 USART1 (RX, TX, RTS, CTS) connected to a 9-way male RS232 connector (J8)
 JTAG, 20-pin IDC connector (J9)
 MicroSD connector (J6)
 SD/MMC connector (J7)
 Gigabit Ethernet ETH0 (J17)
 Ethernet ETH1 (J24)
 Headphone (J15), line (J13)
 Image sensor connector (J11)
 HDMI connector (J25)
 Expansion connector with all LCD controller signals for DM board connection (QTouch, TFT LCD display with
touchscreen and backlight (J21, J22))
 DAA connecter RJ11 6P4C type (J16)
 CAN bus connectors RJ12 6P6C type (J18, J27)
 ZigBee connector (J10)
 Battery socket (J5)
 Three expansion connectors with PIO signals (J1, J2, J3)
 Test points; various test points are located throughout the board
