SAMA5D3x-EK User Guide [USER GUIDE]

11180B–ATARM–29-Oct-13

Table 5-20. PIO B Pin Assignment and Signal Description

Power Rail Signal Signal Signal Signal SAMA5-CM SAMA5-MB

VDDIOP1 PB0 GTX0 PWMH0 PIO GETH CM –

VDDIOP1 PB1 GTX1 PWML0 PIO GETH CM –

VDDIOP1 PB2 GTX2 TK1 PIO GETH CM –

VDDIOP1 PB3 GTX3 TF1 PIO GETH CM –

VDDIOP1 PB4 GRX0 PWMH1 PIO GETH CM –

VDDIOP1 PB5 GRX1 PWML1 PIO GETH CM –

VDDIOP1 PB6 GRX2 TD1 PIO GETH CM –

VDDIOP1 PB7 GRX3 RK1 PIO GETH CM –

VDDIOP1 PB8 GTXCK PWMH2 PIO GETH CM –

VDDIOP1 PB9 GTXEN PWML2 PIO GETH CM –

VDDIOP1 PB10 GTXER RF1 PIO – PWR_MCI0

VDDIOP1 PB11 GRXCK RD1 PIO GETH CM –

VDDIOP1 PB12 GRXDV PWMH3 PIO – PWR_MCI1

VDDIOP1 PB13 GRXER PWML3 PIO GETH CM RX_DV (KSZ9021)

VDDIOP1 PB14 GCRS CANRX1 PIO – CANRX1

VDDIOP1 PB15 GCOL CANTX1 PIO – CANTX1

VDDIOP1 PB16 GMDC PIO PU GETH CM –

VDDIOP1 PB17 GMDIO PIO PU GETH CM –

VDDIOP1 PB18 G125CK PIO PU GETH CM –

VDDIOP1 PB19 MCI1_CDA GTX4 PIO – MCI1_CDA

VDDIOP1 PB20 MCI1_DA0 GTX5 PIO – MCI1_DA0

VDDIOP1 PB21 MCI1_DA1 GTX6 PIO – MCI1_DA1

VDDIOP1 PB22 MCI1_DA2 GTX7 PIO – MCI1_DA2

VDDIOP1 PB23 MCI1_DA3 GRX4 PIO – MCI1_DA3

VDDIOP1 PB24 MCI1_CK GRX5 PIO – MCI1_CK

VDDIOP1 PB25 SCK1 GRX6 PIO INT_GETH0 –

VDDIOP1 PB26 CTS1 GRX7 PIO – CTS1

VDDIOP1 PB27 RTS1 PWMH1 PIO – RTS1

VDDIOP1 PB28 RXD1 PIO PU – RXD1

VDDIOP1 PB29 TXD1 PIO PU – TXD1

VDDIOP0 PB30 DRXD PIO PU – DRXD (DBGU)

VDDIOP0 PB31 DTXD PIO PU – DTXD (DBGU)
