SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
5.4.18 PIO Usage
Table 5-19. PIO A Pin Assignment and Signal Description
Power Rail Signal Signal Signal Signal SAMA5-CM SAMA5-MB
VDDIOP0 PA0 LCDDAT0 PIO PU – LCDDAT0
VDDIOP0 PA1 LCDDAT1 PIO PU – LCDDAT1
VDDIOP0 PA2 LCDDAT2 PIO PU – LCDDAT2
VDDIOP0 PA3 LCDDAT3 PIO PU – LCDDAT3
VDDIOP0 PA4 LCDDAT4 PIO PU – LCDDAT4
VDDIOP0 PA5 LCDDAT5 PIO PU – LCDDAT5
VDDIOP0 PA6 LCDDAT6 PIO PU – LCDDAT6
VDDIOP0 PA7 LCDDAT7 PIO PU – LCDDAT7
VDDIOP0 PA8 LCDDAT8 PIO PU – LCDDAT8
VDDIOP0 PA9 LCDDAT9 PIO PU – LCDDAT9
VDDIOP0 PA10 LCDDAT10 PIO PU – LCDDAT10
VDDIOP0 PA11 LCDDAT11 PIO PU – LCDDAT11
VDDIOP0 PA12 LCDDAT12 PIO PU – LCDDAT12
VDDIOP0 PA13 LCDDAT13 PIO PU – LCDDAT13
VDDIOP0 PA14 LCDDAT14 PIO PU – LCDDAT14
VDDIOP0 PA15 LCDDAT15 PIO PU – LCDDAT15
VDDIOP0 PA16 LCDDAT16 ISI_D0 PIO – ISI_D0
VDDIOP0 PA17 LCDDAT17 ISI_D1 PIO – ISI_D1
VDDIOP0 PA18 LCDDAT18 TWD2 ISI_D2 – ISI_D2
VDDIOP0 PA19 LCDDAT19 TWCK2 ISI_D3 – ISI_D3
VDDIOP0 PA20 LCDDAT20 PWMH0 ISI_D4 – ISI_D4
VDDIOP0 PA21 LCDDAT21 PWML0 ISI_D5 – ISI_D5
VDDIOP0 PA22 LCDDAT22 PWMH1 ISI_D6 – ISI_D6
VDDIOP0 PA23 LCDDAT23 PWML1 ISI_D7 – ISI_D7
VDDIOP0 PA24 LCDPWM PIO PU – LCDPWM
VDDIOP0 PA25 LCDDISP PIO PU – LCDDISP
VDDIOP0 PA26 LCDVSYNC PIO PU – LCDVSYNC
VDDIOP0 PA27 LCDHSYNC PIO PU – LCDHSYNC
VDDIOP0 PA28 LCDPCK PIO PU – LCDPCK
VDDIOP0 PA29 LCDDEN PIO PU – LCDDEN
VDDIOP0 PA30 TWD0 URXD1 ISI_VSYNC – ISI_VSYNC
VDDIOP0 PA31 TWCK0 UTXD1 ISI_HSYNC – ISI_HSYNC
