SAMA5D3x-EK User Guide [USER GUIDE]
11180B–ATARM–29-Oct-13
Table 5-22. PIO D Pin Assignment and Signal Description
Power Rail Signal Signal Signal Signal SAMA5-MB
VDDIOP1 PD0 MCI0_CDA PIO PU – MCI0_CDA
VDDIOP1 PD1 MCI0_DA0 PIO PU – MCI0_DA0
VDDIOP1 PD2 MCI0_DA1 PIO PU – MCI0_DA1
VDDIOP1 PD3 MCI0_DA2 PIO PU – MCI0_DA2
VDDIOP1 PD4 MCI0_DA3 PIO PU – MCI0_DA3
VDDIOP1 PD5 MCI0_DA4 TIOA0 PWMH2 – MCI0_DA4
VDDIOP1 PD6 MCI0_DA5 TIOB0 PWML2 – MCI0_DA5
VDDIOP1 PD7 MCI0_DA6 TCLK0 PWMH3 – MCI0_DA6
VDDIOP1 PD8 MCI0_DA7 PWML3 PIO – MCI0_DA7
VDDIOP1 PD9 MCI0_CK PIO PU – MCI0_CK
VDDIOP1 PD10 SPI0_MISO PIO PU CM_SerFlash –
VDDIOP1 PD11 SPI0_MOSI PIO PU CM_SerFlash –
VDDIOP1 PD12 SPI0_SPCK PIO PU CM_SerFlash –
VDDIOP1 PD13 SPI0_NPCS0 PIO PU CM_SerFlash –
VDDIOP1 PD14 SCK0 SPI0_NPCS1 CANRX0 – CANRX0
VDDIOP1 PD15 CTS0 SPI0_NPCS2 CANTX0 – CANTX0
VDDIOP1 PD16 RTS0 SPI0_NPCS3 PWMFI3 INT_AUDIO –
VDDIOP1 PD17 RXD0 PIO PU – MCI0_CD
VDDIOP1 PD18 TXD0 PIO PU – MCI1_CD
VDDIOP1 PD19 ADTRG PIO PU – ADTRG (HSYNC)
VDDANA PD20 AD0 PIO PU – LCD TSC
VDDANA PD21 AD1 PIO PU – LCD TSC
VDDANA PD22 AD2 PIO PU – LCD TSC
VDDANA PD23 AD3 PIO PU – LCD TSC
VDDANA PD24 AD4 PIO PU – LCD TSC
VDDANA PD25 AD5 PIO PU – EN5V_USBA
VDDANA PD26 AD6 PIO PU – EN5V_USBB
VDDANA PD27 AD7 PIO PU – EN5V_USBC
VDDANA PD28 AD8 PIO PU – OVCUR_USB
VDDANA PD29 AD9 PIO PU – VBUS_SENSE
VDDANA PD30 AD10 PCK0 PIO MCLK_AUDIO MCLK_HDMI
VDDANA PD31 AD11 PCK1 PIO – ISI_MCK
