SAMA5D3x-EK User Guide [USER GUIDE]

11180B–ATARM–29-Oct-13

Table 5-23. PIO E Pin Assignment and Signal Description

Power Rail Signal Signal Signal SAMA5-CM SAMA5-MB

VDDIOM PE0 A0/NBS0 I – –

VDDIOM PE1 A1 I NOR – –

VDDIOM PE2 A2 I NOR – –

VDDIOM PE3 A3 I NOR – –

VDDIOM PE4 A4 I NOR – –

VDDIOM PE5 A5 I NOR – –

VDDIOM PE6 A6 I NOR – –

VDDIOM PE7 A7 I NOR – –

VDDIOM PE8 A8 I NOR – –

VDDIOM PE9 A9 I NOR – –

VDDIOM PE10 A10 I NOR – –

VDDIOM PE11 A11 I NOR – –

VDDIOM PE12 A12 I NOR – –

VDDIOM PE13 A13 I NOR – –

VDDIOM PE14 A14 I NOR – –

VDDIOM PE15 A15 SCK3 NOR – –

VDDIOM PE16 A16 CTS3 NOR – –

VDDIOM PE17 A17 RTS3 NOR – –

VDDIOM PE18 A18 RXD3 NOR – –

VDDIOM PE19 A19 TXD3 NOR – –

VDDIOM PE20 A20 SCK2 NOR – –

VDDIOM PE21 A21/NANDALE I NOR / NAND – –

VDDIOM PE22 A22/NANDCLE I NOR / NAND – –

VDDIOM PE23 A23 CTS2 NOR – –

VDDIOM PE24 A24 RTS2 Power LED ISI_RST –

VDDIOM PE25 A25 RXD2 1-Wire / User LED 1-Wire –

VDDIOM PE26 NCS0 TXD2 CS NOR – –

VDDIOM PE27 NCS1 TIOA2 – PB_USER1 LCDDAT22

VDDIOM PE28 NCS2 TIOB2 – ZB_SLPTR LCDDAT23

VDDIOM PE29 NWR1/NBS1 TCLK2 – ZB_RST –

VDDIOM PE30 NWAIT I – ZB_IRQ1 INT_ETH1

VDDIOM PE31 IRQ PWML1 – ZB_IRQ0 HDMI_INT
