3.0 Setting up and starting up
3.2 Illustrations
Variotherm plus
3 0
3 7
—
 

  

11

3
[
[
0
3
0 4
4
[
   

Fig. 1. Front view
1
Mainswitch
2
KeyswitchforheatingON/OFF(energysaving
mode)
3
Codingswitchforwarm-stimulationlevel
4
Codingswitchforcold-stimulationlevel
5
Codingswitchforstimulationtime
6
Keyswitchforselectingtheirrigationlevel(37°C)
7
Keyswitchforselectingthewarm-stimulationlevel
(e.g.44°C)
8
Keyswitchforselectingthecold-stimulationlevel
(e.g.30°C)
9
Keyswitchforstart/stopofthestimulation
10
Temperaturedisplay(two-gurenumber,resolution
1°C),currentvalueindication
11
Displayofstimulationtime(two-gurenumber,
resolution1s)
