HSP588
Use and maintenance manual pag. 26
4.2 Control pannel
The control panel, located on the left side of the machine, includes other electric controls:
(A) main switch
(C) switch for feeding in and moving back the material (■)
(D) potentiometer for travelling head return displacement
(E) lamp switch
(F) cut-counter switch (○)
(Q)cut-counter device (optional)
(T) potentiometer for striking plate ascent waiting time
(U) selector for feeding rolls opening and closing (■)
■= only for machine equipped with feeder
○= only for machine equipped with cut-counter
Fig. 2
(A)
(C)
(D)
(T)
(E)
(F)
(Q)
(U)
