HSP588
Use and maintenance manual pag. 9
1.3 Acoustic emission of the machine
Features of working and NOT OPERATIVE machine
Leq < 70 dB (A)
Lpc < 130 dB (C)
Features of working and OPERATIVE machine
1) Hide or synthetic leather, thickness 1.5÷2 mm at 15 SPM
- with 1 layer Leq = 79 dB (A) and Lpc < 130 dB (C)
- with 4 layers Leq = 84 dB (A) and Lpc < 130 dB (C)
2) Reclaimed leather, thickness 2 mm at 20 SPM
- with 4 layers Leq = 75 dB (A) and Lpc < 130 dB (C)
NOTE:
The index level depends on the carrying out working (as well as on the machine setting up conditions); the
index levels of any working are reported as an example.
CAPTION
Leq: equivalent continuous level of acoustic pressure at operator site
Lpc: level of sound pressure peak at operator site
1.4 Programmed cut-counting device (optional)
The travelling head press SP588 can be equipped, by request, with a programmed cut-counting device; in
this case it is necessary point out as follows:
IMPORTANT: when it is reached the programmed number of cuts, the travelling head DO NOT EXECUTE its
automatic return but it stops, when the cut has been performed, over the die. Disable the cut-counting
device and use the proper pushbuttons to move the travelling head.
