Atom HSP588 - Table 23: Roll Holder Mounting Parts

HSP588
Use and maintenance manual pag. 69
6.23 Table 23
01000042
01000032-4 rolls  500mm. max
01000034-8 rolls  500mm. max
01000213-12 rolls  300mm. max
01000037-16 rolls  200mm. max
01001925-20 rolls  300mm. max
02000129
02000353
01001732
01000047
01000048
01000046 for rolls 1600 mm. width
01000891 for rolls 2000 mm. width
01000038 for rolls 1600 mm. width
01000890 for rolls 2000 mm. width
