12 • Aircraft Systems
Garmin G1000
Enroute
PFD: Active with appropriate nav source (needles) active.
MFD: Map page with Trac Information active. Range selected to view two
future xes.
G1000 Standard Conguration
Full Panel Approaches
PFD: Active with appropriate nav source (needles) active.
MFD: Map page with Trac Information active. Range selected to view one
or two future xes.
Partial Panel Approaches
PFD: Dimmed.
MFD: Reversionary Mode.
Map Overlay: On with Trac Information active.
G1000 Partial Panel Conguration
