ATV EXS-3 - Assembly Guide

5
Setup (EXS-5)
Assembly Guide
Connect tubes A to E as the gure right shows.
*A corresponding label (A to E) is attached to
each tube.
1
Insert tube A into the tube C clamp
2
Insert tube A and tube B into the clamps at the ends of tube D
Tube A
Tube A
Stand L
*Securely tighten
the clamp bolts
*Securely tighten the clamp bolt
Tube B
Tube D
Tube C
