Figure 7. The insertion and locking of QBH fiber.
Installation of Electricity and gas
A230E electric fiber laser cutting head has already been integrated with motor, driver and
controller, while its power supply and controlling signal have been integrated in the five-pin aerospace
plug of M16 showed as figure 8.
Figure 8. Interface of power supply and signal cable.
