Installation of Water cooling
A230E electric fiber laser cutting head has two water cooling circuits, you could self-configure the
direction of water in and out. Kindly suggest you to use water cooling once the laser power is above
500w. The position and quantity of water cooling interface showed as below (Figure 4). The water
cooling interface is a closed-loop design, but the cooling water can also be provided from the external
and must be following the instructions showed as below:
Figure 4. The interface of water cooling of A230E electric fiber laser cutting head.
