Chapter 4
Using the APC100
The APC100 universal configuration & control unit is a multifunctional device which can
be used as a configuration tool for matrix systems & peripherals, while another typical
application is the use as network gateway.
Using as a configuration tool
When using the APC100 as a configuration tool, it will establist the link between the
matrix, the periperal devices and the computer (network). For making the actual con-
figuration, the ‘AUDAC system manager’ software is required. This software is freely
available and can be downloaded from the AUDAC website.
This windows compatible software application will detect all ‘smart’ devices with their
peripherals in your system and allows extended configuration, update and backup
functions of the equipment.
Using as a gateway
When the APC100 is being used as a gateway, it allows connection to and control through
any TCP/IP based network for all devices containing an RS-232 or RS-485 interface
with APC100 supported baudrate. (19200 baud).
The commands sent to the IP address of the APC100 on port 5001 will be translated
and converted to commands on the RS-232 and RS-485.
This way, any device containing RS-232 (Eg: power amlifier) can be connected to
your LAN network and controlled through a TCP-IP based automation system.
