Audient EVO 4 User Manual

INSTALLATION / SETUP
EVO 4 will also work on iOS and iPadOS devices allowing you to record
and create while on the go. The Setup will dier slightly depending on
what iOS device you are using.
INSTALLATION / SETUP IOS
The Active USB hub is required as the lightning port cannot provide
enough bus power for the EVO 4 to work correctly and the hub will
provide the correct power via the USB cable.
First connect the Camera connection kit to the iPad. Now plug the USB
hub into the USB port on the camera connection kit.
Plug the USB hub into a mains power socket and nally connect EVO 4
to one of the ports on the USB hub.
To use EVO 4 with an iPad Pro, simply connect it using a USB-C to USB-C
cable (not included). The USB-C port on iPad Pro will provide full USB
bus power for the EVO 4 meaning you do not need any external power
source.
Once connected, the iPad will automatically use EVO 4 as the sound
device.
iPAD PRO WITH USBC PORT
Once connected, the iOS device will automatically use EVO 4 as the sound
device. For details on how to setup EVO 4 in recording applications such
Cubasis or Auria Pro, please refer to the developers documentation.
For details on how to setup EVO 4 in recording applications such Cubasis
or Auria Pro, please refer to the developers documentation.
iPAD, iPAD AIR, iPHONE WITH LIGHTNING PORT
In order to connect EVO 4 to a iOS device with a lightning port you will
need the following:
Mains
01 Apple Camera Connection Kit
02 An Active USB Hub
USB Cable
Camera
Connection Kit
USB Hub

Audient EVO 4 Specifications

General

Type	Audio Interface
Number of Preamps	2
Bit Depth	24-bit
Bus Powered	Yes
Direct Monitoring	Yes
Loopback	Yes
Phantom Power	48V
Sample Rate	96 kHz
Inputs	2 x XLR/TRS Combo
Outputs	2 x TRS
Simultaneous I/O	4 in / 4 out
USB	USB-C
Driver	Class Compliant
