Specifications
Page
32
DCX-127
Multifunction
Module
User’s
Guide
MISCELLANEOUS
All
digital
input/output
is
LSTTL/CMOS
compatible.
Outputs
in
series
with
390
W
resistors.
Input
resistance
typically
100
k
W
.
Maximum
rated
input
0
–
5V
.
Output
drive
+5mA/bit
maximum.
Dimensions
17
in.
Wide,
1.75
in.
High,
10.5
in.
deep
Operating
temperature
+
5°C
to
+40°C,
<80%
relative
humidity
Power
requirements
100/120/220/240
V
ac
+
5/-10%);
48-63
Hz;
20
V
A
maximum
36
Table of Contents
Table of Contents
3
Safety Information
4
Safety Symbols
5
Disclaimer
5
Description
6
Scope of this Manual
6
Introduction
6
DC Voltage Measurements
7
Resistance Measurements
8
DC Voltage Outputs
10
Digital Input
11
Digital Output
12
Program Control Outputs
13
Auxiliary Output Ports
15
Installation
16
Mounting
16
Primary Power Considerations
16
Checking or Changing Power Line Voltage
16
Fuse Information
18
Changing Fusing Arrangement
19
Power Switch
20
Proper Environment
20
Connecting the APIB Interface
21
Operation
22
Panel
22
Volts/Ohms Measurements
23
DC Output 1 and 2 On/Off
26
DC Output 1 and 2 Value
26
Digital Input and Output
27
Program Control, Gate Delay
30
Auxiliary Outputs
31
Specifications
34
