Audio Technica AT-LP60X User Manual

10
Replacing the belt
5. Place the belt on the motor pulley (brass-colored).
•
Grasp the belt that was attached in step 3 and, while
pulling it, place it on the brass motor pulley.
6. Using your hands, rotate the platter ten times.
•
Slowly rotate the turntable ten times by hand in the
direction of the arrow.
When the turntable is moved
Using the product's original packing materials, wrap the
turntable in the reverse order from when you unwrapped it. If
you do not have the packaging materials, take the following
measures:
•
After disconnecting the AC adapter from the outlet, remove
the felt mat and platter, and then wrap them so that they do
not get damaged.
•
Attach the protector to the cartridge.
•
Use a string or something similar to tie the tonearm to the
rest so that it does not move.
•
Wrap the turntable body with paper or a soft cloth so that it
does not get damaged.
Place the belt
Motor pulley
(brass-colored)

Audio Technica AT-LP60X Specifications

General

Type	Fully Automatic Belt-Drive Turntable
Drive Method	Belt Drive
Speeds	33-1/3 RPM, 45 RPM
Turntable Platter	Aluminum
Phono Pre-Amp	Built-in switchable phono pre-amplifier
Output	RCA
Motor	DC servo-controlled
Phono Pre-Amp Gain	36 dB nominal, RIAA equalized
Cartridge	ATN3600L
Replacement Stylus	ATN3600L
Weight	2.6 kg
Wow and Flutter	< 0.25% (WTD) @ 3 kHz
Signal-to-Noise Ratio	50 dB
Output Level	Pre-amp 'PHONO': 2.5 mV nominal at 1 kHz, 5 cm/sec; Pre-amp 'LINE': 150 mV nominal at 1 kHz, 5 cm/sec
Stylus	0.6 mil Conical Diamond Stylus
Dimensions	359.5 mm x 97.5 mm x 373.3 mm
