5
Preparation for use
Installing the turntable
•
Mount the product on a level surface.
•
To avoid the effects of vibrations and acoustic pressure, do
not mount the product next to such items as speakers.
•
The product may pick up radio static if placed next to a radio.
Therefore, try to keep the product away from radios.
•
If the product is near equipment (cell phone, etc.) that emits
strong radio waves, noise may occur.
Installing/removing the dust cover
When removing the dust cover, slowly pull the dust cover out
from the dust cover hinge holders. When attaching the dust
cover, insert the hinges of the dust cover into the two dust
cover hinge holders on the back of the body.
Assembling the product
This product requires some assembly before using it for the
first time.
Do not connect the AC adapter until assembly is complete.
1. Set the platter on the spindle.
•
Make certain that the platter is fully seated on the spindle.
2. Place the belt on the motor pulley (brass-colored).
•
Align one of the platter openings with the brass motor
pulley, and, while pulling both ends of the red ribbon that
comes attached to the belt, place the belt on the motor
pulley, as per the diagram. When doing this, be careful not
to twist the belt.
3. Remove the red ribbon from the belt.
4. Set the felt mat on the platter.
•
After setting the felt mat, put the 45 RPM adapter into the
space made for it on the upper left.
Felt mat
45 RPM adapter
Opening Platter
Spindle
Motor pulley
(brass-colored)
Hinge
Straight Twisted
Motor pulley
(brass-colored)
Belt
Red ribbon
To Next Page
