System Features (single-channel)
• True Diversity operation for resistance to multi-path interference and dropouts
• UHF reception with up to 996 frequencies selectable in 25 kHz steps
• Automatic frequency scanning for easy selection of open channels
• Tone Lock
™
squelch system eliminates interference when transmitter is off
• Balanced output on receiver allows connection to a balanced microphone-level
input on camera, mixer or amplifier
• Headphone monitor output with independent level control
• Battery fuel-level indicators on transmitters and receiver
• Soft-touch controls for easy frequency selection
• LCD frequency and battery status display with backlight on receiver and
transmitters
• Antenna and AF Peak LED indicators
• Compact receiver ideal for on-camera use
• Transmitters operate in low or high transmission modes to conserve battery
life/maximize power
• Easy, user-friendly operation
• Clear, natural sound quality
• Powered by AA batteries or external 12V DC power (not included)
• System components of the 1800 Series and 3000 Series UHF Wireless Systems
can be used interchangeably*
*Note: The 1800 Series offers UHF Wireless operation frequencies in 25KHz step, therefore
the 1800 transmitters and receivers feature up to 996 selectable frequencies (depending on
the frequency band).
The components of the 1800 Series and 3000 Series are compatible, however considering
that transmitters and receivers of the 3000 Series operate only on 200 programmed
frequencies, a system composed of mixed element from 1800 Series and 3000 Series will
only operate on the 200 pre-programmed frequencies of the 3000 element.
Be certain to set each transmitter receiver pair to identical frequencies.
4
