INSTALLATION AND POWER
page 1 – 10
CUE Out – RJ-45
Signals is analog mono; balanced.
Pin 1 – HI
Pin 2 – LO
PGM Out – RJ-45
The four PGM1 - PGM4 analog stereo balanced program outputs and one PGM 1 AES
digital output.
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Pin 1 – HI
Pin 2 – LO
Control Room Out – RJ-45
The signal is analog stereo; balanced.
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Studio Out – RJ-45
The signals are analog stereo; balanced.
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Pin 1 – HI
Pin 2 – LO
Pin 3 – HI
Pin 6 – LO
Control Connections
Functions include remote on and off, tally, and start/stop for remote source machines.
The Start, Stop, Tally ON, and Tally OFF ports are opto-isolated.
1 - 4 Logic I/O – RJ-45
RJ-45 Pin 1 – Digital Ground
RJ-45 Pin 2 – Start
RJ-45 Pin 6 – Remote OFF
RJ-45 Pin 7 – Remote ON
RJ-45 Pin 8 – +5V Digital
PGM1 AES OUT
PGM LT OUT
PGM RT OUT
CUE OUT
STU PRE LT OUT
STU PRE RT OUT
CR LT OUT
CR RT OUT
STU LT OUT
STU RT OUT
