AudioArts Lightning / June 2018
CONTROLS AND FUNCTIONS
page 2 – 3
Controls and Functions
Input Panel
Each Input panel of the Lightning console has four identical input strips.
Sources
Input channels have A/B source
selection, with balanced line in for
the A source and trimmable -10 to
+4 line in on B.
Recessed front panel trimpots,
located underneath the hinged
meterbridge, adjust the left and
right levels of the B source.
The Light ning console is
designed to handle up to 16 analog
stereo line inputs. These inputs
are typically used to connect to
machines, such as tape decks, cart
machines, CD players, etc., that
provide analog outputs.
The console also contains a
patchable AES input for connecting
a digital source to any fader, and
built-in A/D conversion for the
main program output so operators
can access the Program air feed as
balanced analog, AES3 digital, or
both simultaneously.
Additional four channel mic
preamp card can be tted if needed.
