APPENDICES
COMPONENT DESCRIPTION WS P/N
AEL-IP MODULE
COMPLETE INPUT MODULE
012300
AEL-MSTR MODULE
COMPLETE MASTER MODULE
012301
AEL-IP LOADED CARD
INPUT PANEL LOADED CARD ASSEMBLY
012322
AEL-MSTR LOADED CARD MASTER PANEL LOADED CARD ASSEMBLY
012324
AEL-MIC LOADED CARD MICROPHONE LOADED CARD ASSEMBLY
012326
AEL-VU LOADED CARD VU METERS LOADED CARD ASSEMBLY
012328
AEL-PWI LOADED CARD POWER INTERFACE LOADED CARD ASSEMBLY
012320
AEL-BT LOADED CARD BLUETOOTH LOADED CARD ASSEMBLY
012329
AEL BLANK FACEPLATE BLANK FACEPLATE 6.5”
012356
FADER 100MM 10K DUAL AUDIO COND PLASTIC FADER
540073
POT “STUDIO” 10K DUAL AUDIO POT w/1/4” SHAFT
500029
POT “CUE” 10K SINGLE LINEAR POT w/30MM SHAFT
520136
FADER KNOB WHITE FADER KNOB WITH BLACK LINE
520051
POT KNOB 21MM BLACK KNOB FOR “STUDIO” POT
520124
POT KNOB 15MM BLACK PUSH-ON KNOB FOR “CUE” POT
520125
POT CAP 11MM BLACK CAP w/WHITE LINE KNOB FOR “CUE” POT
530037
POT CAP 21MM BLACK CAP w/WHITE LINE KNOB FOR “STUDIO” POT
530319
SWITCH LAKEVIEW SWITCH w/SMALL CLEAR CAP & YELLOW LED
530315
SWITCH LAKEVIEW SWITCH w/LARGE CLEAR CAP & WHITE LED
530316
SWITCH LAKEVIEW SWITCH w/LARGE CLEAR CAP & BLUE LED
530317
SWITCH LAKEVIEW SWITCH w/SMALL CLEAR CAP & RED LED
530319
CONNECTOR 4x2 STACKED R/A SHIELDED RJ-45 CONNECTOR
260086
CONNECTOR 2x2 STACKED R/A SHIELDED RJ-45 CONNECTOR
260089
CONNECTOR USB-B R/A SHIELDED RJ-45
260090
RTS JACK HEADPHONE JACK
260005
HEADER 3 PIN HEADER
250062
HEADER 6 PIN HEADER
250065
HEADER 6 PIN R/A HEADER
250163
HEADER 3-CIRCUIT R/A HEADER W/MOUNTING TABS
270094
POWER SUPPLY SPS-130 RACKMOUNT POWER SUPPLY +/-16V 130W
007570
POWER SUPPLY CABLE CABLE TO CONNECT CONSOLE AND POWER SUPPLY
007575
POWER CONNECTOR POWER CONNECTOR W/PC TERMINALS, AC
230071
POWER CORD 7 1/2” BLACK POWER CORD
150017
SPEAKER CONSOLE METERBRIDGE SPEAKER
960016
MANUAL TECHNICAL MANUAL FOR LIGHTNING CONSOLE
012399
REPLACEMENT PARTS - LIGHTNING CONSOLE
