PAETEC and Microsoft Lync Integration 70 Document #: LTRT-33420
Mediant 800/1000/3000 E-SBC
5.14 Step 15: Configuring for Gateway Registration
This section describes how to configure the SIP Proxy and Registration parameters to
support Gateway Registration.
¾ To configure the SIP Proxy and Registration parameters:
1. Open the 'SIP General Parameters' page (Configuration tab > VoIP menu > SIP
Definitions submenu > Proxy & Registration Parameters).
Figure 5-35: SIP Proxy & Registration Parameters Page
2. In the ‘Enable Registration’ drop-down list, select Enable.
3. In the ‘Registrar IP Address’, enter the address supporting the registrar.
[64.199.64.220]
4. From the ‘Registrar Transport Type’ drop-down list, select UDP.
5. From the ‘User Name’, enter the valid number for registration of the gateway
device. [2814022036].
6. From the ‘Registration Mode’ drop-down list, select Per Gateway.
7. Once completed, select Submit and then Register.
8. Reset the device with the Burn option to ensure that it maintains its datafill after
restart.
2
3
7
6
4
5
