Register 7: Options
Digital inputs and signal loss
at analogue inputs
Register 8: First analogue input (wiring diagram designation analogue 2)
The data content depends on parameter 22 (coding analogue 2), holding
register offset: 0x4015 (hexadezimal), 16405 (dezimal)
Settings:
0: 0 to 100 percent (default value)
1: 0 to 1000 per mil
2: 0 to 1023 (raw value of analogue-digital converter, not standardised)
29
Actuator controls AUMA MATIC AM/ AMExB/ AMExC
Operation instructions Modbus
4
Remote
OPEN
1
Remote operation via Modbus in direction OPEN (re
-
mote operation bit for logic board set and movement of
potentiometer detected). Signalling of this bit requires
a position transmitter.
0 other
5
Remote
CLOSE
1
Remote operation via Modbus in direction CLOSE (re-
mote operation bit for logic board set and movement of
potentiometer detected). Signalling of this bit requires
a position transmitter.
0 other
6
Local OPEN
1
Actuator runs locally in direction OPEN (local controls
or handwheel).
Signalling of this bit requires a position transmitter.
0 other
7
Local
CLOSE
1
Actuator runs locally in direction CLOSE (local controls
or handwheel). Signalling of this bit requires a position
transmitter.
0 other
Bit Designation Value Description
0
Dig.
input 1
1 Digital input Nr. 1 = 1 (switch closed)
0 Digital input Nr. 1 = 0 (switch open)
1
Dig.
input 2
1 Digital input Nr. 2 = 1 (switch closed)
0 Digital input Nr. 2 = 0 (switch open)
2
Dig.
input 3
1 Digital input Nr. 3 = 1 (switch closed)
0 Digital input Nr. 3 = 0 (switch open)
3
Dig.
input 4
1 Digital input Nr. 4 = 1 (switch closed)
0 Digital input Nr. 4 = 0 (switch open)
4
—
1
Not assigned (reserved for extensions)
0
5
Analogue 2
loss
1
Signal interrupted at analogue input 2 (first free ana-
logue input) i.e. the measured value is more than 0.2
mA lower than the set minimum value.
0 no signal interruption analogue input 2 detected
6
Analogue 3/4
loss
1
Signal interrupted at analogue input 3/4 (second free
analogue input) i.e. the measured value is more than
0.2 mA lower than the set minimum value.
0 no signal interruption analogue input 3/4 detected
7
—
1
not assigned (reserved for extensions)
0
