DescriptionDesignation
(process representation)
Prm-Text-Def GSD file
Warning:
Optical receiving signal (channel 1) incorrect (no or insuffi-
cient Rx receive level) or RS-485 format error (incorrect
bit(s))
Bit: Wrn FO cables
(83) = "Bit: Wrn FO ring"
Warning on time max. running time/h exceeded
Bit: WrnOnTiRunning
(84) = "Bit: WrnOnTiRunning"
Warning on time max. number of motor starts (starts) ex-
ceeded
Bit: WrnOnTiStarts
(85) = "Bit: WrnOnTiStarts"
Parameter not available
Bit: WrnOnTiRunning
(86) = "Bit: Wrn vibration"
Parameter not available
Bit: WrnOnTiStarts
(87) = "Bit: Wrn dew point"
Warning: Temperature within controls housing too high
Bit: Wrn controls temp
(88) = "Bit: WrnControlsTemp"
Parameter not available
Bit: Wrn motor temp
(89) = "Bit: Wrn motor temp."
Parameter not available
Bit: Wrn gearbox temp
(90) = "Bit: Wrn gearbox temp."
Warning: Loss of signal analogue input 1
Bit: Wrn input AIN 1
(91) = "Bit: Wrn input AIN 1"
Warning: Loss of signal analogue input 2
Bit: Wrn input AIN 2
(92) = "Bit: Wrn input AIN 2"
Warning: Loss of signal actual process value
Bit: WrnActProcVal
(93) = "Bit: WrnActProcVal"
Warning: Loss of signal process setpoint
Bit: WrnProcSetpoint
(94) = "Bit: WrnProcSetpoint"
Warning: Loss of signal of actuator setpoint position
Bit: WrnSetpointPos
(95) = "Bit: WrnSetpointPos"
Fieldbus failure
Bit: Fieldbus failure
(96) = "Bit: Fieldbus failure"
A local STOP is active.
Push button STOP of local controls is operated.
Bit: Local STOP
(97) = "Bit: Local Stop"
Wrong operation command
Indicates that several operation commands were received
simultaneously via Profibus DP (e.g. Remote OPEN and
Remote CLOSE simultaneously or Remote CLOSE/Remote
OPEN and Remote SETPOINT simultaneously) or that the
max. value for a setpoint position has been exceeded (set-
point position > 1,000).
Bit: Wrong oper. cmd
(98) = "Bit: Wrong operation cmd"
Channel 1 is the active operation command channel.
Bit: Channel 1 active
(99) = "Bit: Channel 1 active"
Channel 2 is the active operation command channel.
Bit: Channel 2 active
(100) = "Bit: Channel 2 active"
Motor runs in direction CLOSE.
Bit:Motor runs CLOSE
(101) = "Bit: Motor running Close"
Motor runs in direction OPEN.
Bit:Motor runs OPEN
(102) = "Bit: Motor running Open"
Time synchronisation is active.
Bit: DP TimeSynch (Set-
Prm)
(103) = "Bit: Time Sync active"
The Interlock function prevents an operation in operation
mode REMOTE.
Bit: Interlock Remote
(104) = "Bit: Interlock Remote"
The Interlock function prevents an operation in operation
mode LOCAL.
Bit: Interlock Local
(105) = "Bit: Interlock Local"
The Interlock function prevents an operation in operation
mode REMOTE or in operation mode LOCAL.
Bit: Interlock
(106) = "Bit: Interlock"
Operation mode disabled.
Bit: Disabled
(107) = "Bit: Disabled"
Warning: Configuration setting is incorrect.
The device can still be operated with restrictions.
Bit: Config. warning
(108) = "Bit: Config. Warning"
Channel 1 is in the data exchange state (DataEx).
Bit: Channel 1 DataEx
(109) = "Bit: Pb DataEx Ch1"
Channel 2 is in the data exchange state (DataEx).
Bit: Channel 2 DataEx
(110) = "Bit: Pb DataEx Ch2"
Warning: FO cable system reserve reached (critical or per-
missible Rx receive level)
Bit: Wrn FOC budget
(111) = "Bit: Wrn FOC budget"
No valid fieldbus communication via channel 1 (application
does not communicate with the DCS).
Bit: Chan 1 FailState field-
bus
(112) = "Bit: FieldbusFailsafeAct.1"
No valid fieldbus communication via channel 2 (application
does not communicate with the DCS).
Bit: Chan 2 FailState field-
bus
(113) = "Bit: FieldbusFailsafeAct.2"
Bus communication available on channel 1.
Bit: Channel 1 activity
(114) = "Bit: Chan1 BusComm"
Bus communication available on channel 2.
Bit: Channel 2 activity
(115) = "Bit: Chan2 BusComm"
Partial Valve Stroke Test (PVST) is active.
Bit: PVST active
(116) = "Bit: PVST active"
Partial Valve Stroke Test (PVST) could not be successfully
completed.
Bit: PVST error
(117) = "Bit: PVST fault"
15
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Commissioning
