DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
No signal (reserved)——5
No signal (reserved)——6
No signal (reserved)——7
Byte 25: Out of specification 1
Causes of the Out of specification signal in accordance with NAMUR recommendation
NE 107.
Table 20: Byte 25: Out of specification 1
DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
No signal (reserved)——0
No signal (reserved)——1
No signal (reserved)——2
No signal (reserved)——3
Warning: Limit value for Torque warning CLOSE ex-
ceeded
1(125) = "Bit: Torque wrn
CLOSE"
Bit: Torque warn. CLOSE
4
No signal0
Warning: Limit value for Torque warning OPEN exceeded1(124) = "Bit:Torque wrn
OPEN"
Bit: Torque warn. OPEN
5
No signal0
Warning: A SIL fault of the SIL sub-assembly has oc-
curred.
1(206) = "SIL fault"
Bit: SIL fault
1)
6
No signal0
Warning: No actuator reaction to operation commands
within the set reaction time.
1(71) = "Bit: No reaction"
Bit: No reaction
7
No signal0
The safety function indications via fieldbus are for information only and must not be used as part of a safety function.The I/O signals of
the SIL module must be used for this purpose.
1)
Byte 26: Out of specification 2
Table 21: Byte 26: Out of specification 2
DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
Warning: Temperature within controls housing too high1(88) = "Bit: WrnControl-
sTemp"
Bit: Wrn controls temp
0
No signal0
No signal (reserved)——1
No signal (reserved)——2
The external 24 V DC voltage supply of the controls has
exceeded the power supply limits.
1(68) = "Bit: 24 V DC, extern-
al"
Bit: 24 V DC, external
3
No signal0
No signal (reserved)——4
Warning: The voltage of the RTC button cell is too low.1(126) = "Bit: RTC button
cell"
Bit: RTC button cell
5
No signal0
The real time clock has not yet been set on the basis of
valid values.
1(77) = "Bit: RTC not set"
Bit: RTC not set
6
No signal0
Warning: Configuration setting is incorrect.
The device can still be operated with restrictions.
1(108) = “Bit: Config. Warn-
ing”
Bit: Config. warning
7
No signal0
31
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Description of the data interface
