Value and descriptionIndication in display
Global Control Sync Status
DP1 GC sync M059
With the Unsync Global Control telegram is the Sync state is
deactivated again.
GC Sync inactive
The Sync Global Control telegram can be used to freeze the
Profibus DP outputs (operation commands).
GC Sync active
Configuration data (number of input and output bytes) set by the master.
DP1 config. data M1195
Table 42: Profibus details
Value and descriptionIndication in display
In this state, the actuator can only be operated by means of the acyclic Profibus DP-V1
services (only possible if there is no cyclic DP-V0 connection available.
DP-V1 control
At least one acyclic Profibus DP-V1 connection is active.
DP-V1 active
Profibus interface of channel 1 is used.
Channel 1 active
Profibus interface of channel 2 is used.
Channel 2 active
Profibus DP2 (Profibus DP, channel 1)
Primary
No channel is used as primary channel.
None
Channel 1 is used as primary channel.
Channel 1
Channel 2 is used as primary channel.
Channel 2
Profibus DP2 (Profibus DP, channel 2)
Backup
No channel is used as backup channel.
None
Channel 1 is used as backup channel.
Channel 1
Channel 2 is used as backup channel.
Channel 2
The actuator controls are assigned different ident numbers depending on the function.
Profibus ID no.
For Profibus DP-V0 and DP-V1
0x0C4F
for Profibus DP-V0 and DP-V1 including the DP-V2 functions
Redundancy with time synchronisation, time stamp and alarms.
0x0CBD
Redundancy
Redundancy
No redundancy available.
None
Redundancy activated according to Profibus DP-V2 (SR).
DP-V2 (SR)
Redundancy activated according to Profibus DP-V2 (FR).
DP-V2 (FR)
General Profibus DP redundancy (AUMA redundancy I)
AUMA redundancy I
AUMA redundancy II
AUMA redundancy II
DP-V1 function in the parameter telegram (SetPrm)
DP-V1 (SetPrm)
The DP-V1 services were deactivated using the parameters in
the parameter telegram (SetPrm).
Deactivated
The DP-V1 services were activated using the parameters in the
parameter telegram (SetPrm).
Activated
Signalling alarms in the parameter telegram (SetPrm)
Alarms (SetPrm)
The alarms were deactivated using the parameters in the para-
meter telegram (SetPrm).
Deactivated
The alarms were activated using the parameters in the parameter
telegram (SetPrm).
Activated
Redundancy function in the parameter telegram (SetPrm)
Redundancy (SetPrm)
The redundancy function according to Profibus DP-V2 was deac-
tivated using the parameters in the parameter telegram (SetPrm).
Deactivated
The redundancy function according to Profibus DP-V2 was activ-
ated using the parameters in the parameter telegram (SetPrm).
Activated
Response behaviour (response) for AUMA redundancy II
Behaviour Tx
Profibus DP response telegrams are exclusively sent via the
active channel
Tx active channel
Profibus DP response telegrams are sent via both channels.
Tx both channels
55
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Corrective action
